Suspension set-up for TL1000R |
Here's the road and race
settings...great handling, neutral steering...... a fast easy to ride bike.
The TL-R is a very sensitive bike to suspension and ride height changes. ROAD SETTINGS:
This gives you good feel and composure over bumpy
roads,
Tire Pressures: Front 36 PSI Rear 36 PSI FRONT Suspension Settings: Spring Preload: 4 Lines showing (fourth line
should just show above cap)
Compression Damping: 10 clicks out from fully in Rebound Damping: 5 clicks out from fully in REAR Suspension Settings: Spring Preload: 6 threads showing on top side
of the thread below the lock ring
Compression Damping: 18 clicks out from fully in Rebound Damping: 15 clicks out from fully in
RACETRACK SETTINGS:
Good control and feedback for Trackdays and
Tire Pressures: Front 32 PSI Rear 32 PSI FRONT Suspension Settings: Spring Preload: 4 Lines showing (fourth line
should just show above cap)
Compression Damping: 4 clicks out from fully in Rebound Damping: 3 clicks out from fully in REAR Suspension Settings: Spring Preload: 6 threads showing on top side
of the thread below the lock ring
Compression Damping: 7 clicks out from fully in Rebound Damping: 10 clicks out from fully in
|
